EN – 32
TV60, 480i(525i) – 15.73 59.94 960 x 540 –
TV50, 576i(625i) – 15.63 50.00 960 x 540 –
1080i 60 (1125i 60) – 33.75 60.00 960 x 540 –
1080i 50 (1125i 50) – 28.13 50.00 960 x 540 –
1080i 50a (1250i 50) – 31.25 50.00 960 x 540 –
480p (525p) – 31.47 59.94 960 x 540 –
576p (625p) – 31.25 50.00 960 x 540 –
720p 60 (750p 60) – 45.00 60.00 960 x 540 –
720p 50 (750p 50) – 37.50 50.00 960 x 540 –
PC98 640 x 400 24.82 56.42 960 x 540 640 x 400
CGA70 640 x 400 31.47 70.09 864 x 540 640 x 400
CGA84 640 x 400 37.86 84.13 864 x 540 640 x 400
CGA85 640 x 400 37.86 85.08 864 x 540 640 x 400
VGA60 640 x 480 31.47 59.94 864 x 540 640 x 480
VGA72 640 x 480 37.86 72.81 720 x 540 640 x 480
VGA75 640 x 480 37.50 75.00 720 x 540 640 x 480
VGA85 640 x 480 43.27 85.01 720 x 540 640 x 480
VGA120 640 x 480 61.89 120.17 720 x 540 640 x 480
SVGA56 800 x 600 35.16 56.25 720 x 540 800 x 540
SVGA60 800 x 600 37.88 60.32 720 x 540 800 x 540
SVGA72 800 x 600 48.08 72.19 720 x 540 800 x 540
SVGA75 800 x 600 46.88 75.00 720 x 540 800 x 540
SVGA85 800 x 600 53.67 85.06 720 x 540 800 x 540
SVGA95 800 x 600 59.97 94.89 720 x 540 800 x 540
SVGA120 800 x 600 77.11 119.93 720 x 540 800 x 540
XGA43i 1024 x 768 35.52 86.96 720 x 540 960 x 540
XGA60 1024 x 768 48.36 60.00 720 x 540 960 x 540
XGA70 1024 x 768 56.48 70.07 720 x 540 960 x 540
XGA75 1024 x 768 60.02 75.03 720 x 540 960 x 540
XGA85 1024 x 768 68.68 85.00 720 x 540 960 x 540
MAC13 640 x 480 35.00 66.67 720 x 540 640 x 480
MAC16 832 x 624 49.72 74.55 720 x 540 832 x 540
MAC19 1024 x 768 60.24 75.02 720 x 540 960 x 540
HP75 1024 x 768 62.94 74.92 720 x 540 960 x 540
Specifications (continued)
Specification of RGB signals in each computer mode of the projector
Signal mode resolution horizontal Vertical Normal mode Real mode
(H x V) frequency (kHz) frequency (Hz) (H x V)*1 (H x V)
*1 : When ANAMORPHIC in the FEATURE menu is
set to AUTO.
• When the REAL button on the remote control is
pressed, images are displayed in their original
size. In the REAL mode, images are black-framed
when the image resolution is lower than 960 x
540.
Important:
• Some computers aren’t compatible with the
projector.
• The projector's maximum resolution is 960 x 540
pixels. It may not display images of higher resolu-
tions than 960 x 540 correctly.
• Images with SYNC on G (Green) signal may jitter.
• Images with SYNC on G (Green) signal may be
tinged with green.
• If the resolution and frequency of your computer
aren't shown on the table, find the compatible
resolution and frequency by changing the resolu-
tion of your computer.
• Set COMPUTER INPUT in the SIGNAL menu to
RGB when inputting the HDTV signal as RGB
signal.
• In the case of SXGA, the right side of the image
may not appear. In this case, adjust TRACKING
in the SIGNAL menu.
• TV60 and TV50 are equivalent to 480i and 576i
respectively. When these signals are supplied to
the VIDEO or S-VIDEO signal, the signal mode is
indicated as TV60 or TV50. When they are
supplied to the COMPONENT terminal, the
signal mode is indicated as 480i or 576i.
