44
80 80 50QMA 50QMA N/B Maintenance N/B Maintenance
1.6 Appendix 2: W83L950D KBC Pins Definitions (1)
Port Pin Function Imple me nt
P0 0-7 KO[0..7]
P1 0-7 KO[8..15]
P3 0-7 KI[0..7]
0 LPC enable H8_THRM#
1 GPIO x1 H8_WAKE_UP#
2 BATT_G#
3 BATT_R#
4 EXTSMI#
5 CAP#
6 NUM#
7 SCROLL#
0 H8_ENABKL
1 CHARGING
2 LEARING
3 H8_SUSB
4 KBRST H8_HRCIN#
5 A20 A20GATE
6 H8_SCI
7 H8_PWRON
0 GPIO x1 SW_VDD3
1 H8_LIDSW#
2 BATT_DEAD#
3 H8_ADEN#
4 BATT_LED#
5 KBC_PWRON_VDD3S
6 BLADJ
7 H8_I_CTR
Scan matrix
P2
SMBUS1 or UART
GPIO x4
P4
Xcin/cout or PWM 2,3
GPIO x2 ( INT1 )
GPIO x2
P5
GPIO x3 ( INT20,30,40 )
GPIO x2
D/A, PWM 2,3
