11
• Your tool is supplied with a guard for use with a
depressed center grinding wheel, multi-disc and wire
wheel brush. A cut-off wheel can also be used with an
optional guard. If you decide to use your Makita grinder
with approved accessories which you purchase from
your Makita distributor or factory service center, be sure
to obtain and use all necessary fasteners and guards as
recommended in this manual. Your failure to do so could
result in personal injury to you and others.
If you need any assistance for more details regarding these
accessories, ask your local Makita service center.
C00162
2
3
4
5
6
7
8
2
9
10 11
3
12
5
1
005514
9564 9565
1 Grip 36
2 Wheel guard
3 Inner flange 45
4 Depressed center grinding wheel/Multi-disc
5 Lock nut 5/8-45
6 Rubber pad 100 Rubber pad 115
7 Abrasive disc
8 Sanding lock nut 5/8-48
9 Wire wheel brush
10 Wire cup brush
11 Wheel guard (For cut-off wheel)
12 Cut-off wheel
- Lock nut wrench 28
