19
1 181573 Throttle Trigger and Cable Assembly
2 180942 Handle Bar w/Clamp Assemblies
(includes 3-5)
3 612831 Grip
4 612021 Tube Closure
5 181503 Clamp Assembly
6 147501 Engine Bracket Mounting Hardware
7 181574 Engine Mount Bracket, R.H.
8 181504 Engine Mount Bracket, L.H.
9 682035 Switch Assembly
10 683295 Handle Bracket Assembly
(includes 11-16)
11 181811 Screw
12 181812 Upper Handle Clamp
13 181813 Middle Handle Clamp
14 181814 Lower Handle Clamp
15 181815 Nut
16 145569 Anti-Rotation Screw
17 181575 Grip
18 180943 Drive Shaft Housing Assembly
19 181577 Flexible Drive Shaft
20 181578 Retainer Sleeve (includes 21)
21 180288 Sleeve Retainer Bolt
22 147467 Wheel Bracket Mounting Hardware
23 182781 Guard
24 181579 Guard Mounting Hardware
25 180320 Wheel Bracket Assembly
26 180944 Wheel Assembly
27 147473 Tine Fastener Assembly
28 182729 Tine Assembly (Left Outer or Right
Inner)
29 182730 Tine Assembly (Left Inner or Right
Outer)
30 182750 Gear Box Assembly
* 182780 Arnold 2-Cycle Oil
* not shown
MODEL 21A-120R000
Part No. Part Description
Ref.
No.
Part No. Part Description
Ref.
No.
