MTD 21A-120R000 User Manual
Page 17
17
1.
182059
Air Cleaner/Muffler Cover Assembly
(includes 2 & 41)
2.
180350
Air Cleaner Filter
3.
180351
Carburetor Mounting Screw
Assembly
4.
180226
Wavey Washer
5.
182160
Choke Lever Assembly (includes 6)
6.
182161
Choke Knob and Screw
7.
182162
Choke Lever and Plate (includes 5)
8.
182062
Carburetor Assembly W/Limiter
Caps (includes 9 & 21)
9.
610675
Carburetor Gasket
10.
181860
Carb Mount Screw
11.
181801
Primer and Hose Assembly
12.
182063
Carb Mount Assembly (includes 10)
13.
684451
Reed Assembly
14.
182790
Power Shaft Assembly
15.
612115
Carburetor Mount Gasket
16.
182791
Crank Case Service Assembly
(includes 10, 14 & 24)
17.
612134
Rear Mounting Pad
18.
180046
Fuel Tank Assembly
(includes 19-21)
19.
181559
Fuel Cap Assembly
20.
181168
Fuel Return Line
21.
682039
Fuel Line Assembly
22.
145308
Front Mounting Pad
23.
683065
Shroud Assembly
24.
181861
Shroud Screw
25.
182064
Shroud Extension and Stand
26.
182736
Flywheel Assembly
27.
181065
Spacer
28.
181597
Recoil Pulley Assembly
29.
613102
Recoil Spring
30.
181441
Pulley Retainer Assembly
31.
611061
Rope Guide
32.
180317
Fuel Tank Guard Assembly
33.
181079
Pull Handle
34.
613103
Rope
35.
181912
Housing Screw
36
182776
Starter Housing Assembly
(includes items 28-31, 33-35)
37
182368
Clutch Washer
38
182369
Clutch Rotor Assembly
39
153592
Clutch Drum Assembly
40
180098
Clutch Cover Assembly
(includes 41)
41
181345
Clutch Cover Screw
42
153597
Upper Clamp Assembly
43
181937
Module Assembly
44
181580
Wire Lead
45
610311
Spark Plug
46
182065
Exhaust Gasket
47
182174
Muffler Assembly (includes 46 & 48)
48
182464
Muffler Mounting Bolt Assembly
49
181622
Cylinder Assembly
(includes 51 & 52)
50
684449
Piston and Rod Assembly
51
610674
Cylinder Gasket
52
182723
Cylinder Bolt
*
180011
Engine Gasket Kit
*
180602
O.E.M. Carburetor Repair Kit
(Walbro)
*
180090
O.E.M. Carburetor Repair Kit (Zama)
*
181069
Gasket-Diaphragm Repair Kit
(Walbro)
*
180091
Gasket-Diaphragm Repair Kit
(Zama)
*
180530
Piston Ring
*
182792
Short Block Assembly
(includes 45, 49-52)
*
181501
Starter Housing Screw Set
*
181873
Carburetor Limiter Cap Set (Walbro)
*
181562
Carburetor Limiter Cap Set (Zama)
*
610309
Crankcase Seal
*
181599
Clutch Springs (Qty. 2)
*
not shown
Part No.
Part Description
Ref.
No.
Part No.
Part Description
Ref.
No.
MODEL 21A-120R000
