4 English
B Adjustable Feet
Picture tilt and projection angle can be adjusted by twisting Adjustable Feet. Projection
angle can be adjusted 2° to 8.5° degrees by rotating the front/center foot. The projector is
also equipped with left adjustable foot.
Figure 5 Adjustable feet (left/ right/ middle)
Moving the Projector
Use the carrying handle when moving the projector.
Replace the lens cover and rotate the feet fully clockwise (to shorten the feet) when moving
the projector to prevent damage to the projector.
Figure 6 Moving the projector
Caution Caution Caution Caution
The carrier bag (supplied) is intended to protect the projector from dust and scratches
on the surface of the cabinet. It is not designed to protect the projector from external
shock.
Do not transport the projector in an unsuitable transport case by using a courier or
transport service. This may cause damage to the projector.
