PRODUCT SPECIFICATIONS
3 – 1
SECTION 3
Product Specifications Product Specifications Product Specifications Product Specifications Product Specifications
Models and Capacities Models and Capacities Models and Capacities Models and Capacities Models and Capacities
Performance Specifications Performance Specifications Performance Specifications Performance Specifications Performance Specifications
MODEL S 5T 060 H 6 5T 040 H 4 5T 030 H 3 5T 020 H 2 5T 010 H 1
In tegrated Inter face ATA- 5 / Ultr a ATA
En cod ing Method PRML ( 48 /5 0) EPR4
Inte rlea ve 1:1
Servo Sys tem Embedd ed
Buffer Size / Typ e 2 MB SD RAM
Data Zones p er Sur face 16
D ata Su rfa c es / He ad s 6 4 3 2 1
Nu mber of D i sk s 3 2 2 1 1
Are al D ensi ty 14 .5 Gbi ts / i n 2 max
Tr a ck D ensi ty 34,3 00 tp i
Rec ord in g D ensi ty 34 6 to 423 kb pi
F lu x D ensity 36 0 to 43 9 k fci
Byte s per Sector / Blo c k 51 2
Sector s pe r Trac k 36 0 to 624
Sec tors pe r D rive 120 103 200 80 043 26 4 60 030 43 2 40 021 63 2 20 010 81 6
MODEL S 5T 060 H 6 5T 040 H 4 5T 030 H 3 5T 020 H 2 5T 010 H 1
Seek Times ( typi c al r ead )
Tr ack- to -Trac k 1.0 m s
Aver a ge (pe rfo rm an ce) < 8 .7 m s
Full Str o ke < 20 .0 m s
Ave rage Latency 4.17 m s
Rota ti o nal Spe ed ( ±0 .01 %) 72 00 RPM
Contro ll e r Over he ad < 0 .3 m s
D ata Tran sfer Rate
To/Fr om Interfa ce
( Ultr aD M A - M 5 )
up to 10 0 MBytes/s ec
To/Fr om Interfa ce
( PIO 4 /M ulti -wor d D M A M 5 )
up to 16 .7 MBytes/s e c
To /F rom Medi a up to 5 7 MBytes/s e c
Sta rt Ti m e (0 to D ri v e R ea dy ) 8.5 sec typ i c al
Drive Configuration Drive Configuration Drive Configuration Drive Configuration Drive Configuration
MO DE L S 5 T 06 0 H 6 5 T 04 0 H 4 5 T 03 0 H 3 5 T 02 0 H 2 5 T 01 0 H 1
Fo r ma tte d C a p a ci ty (GB LB A M o d e) 6 1 .5 4 0 .9 3 0 .7 2 0 .4 1 0 .2
M a xto r d efin es o ne m eg ab yte as 10 E6 o r o ne m i ll i on b ytes an d on e gi ga byte as 10 E 9
or one bi ll i on by tes.
