A: Solution 1 for residual image
16 channel: channels are divided into 4 groups as:
(1、5、9、13) ( 2、6、10、14)
(3、7、11、15) (4、8、12、16)
Recording with one input from each group
B: Solution 2 for playback image pasting
Record Chanel \ Record Rate 30fps or less 60fps
1 1
2 2
2
3 4
4 4
4
5 7
6 7
7 7
8 8
8
9 11
10 11
11 11
12 13
13 13
14 14
14
15 16
Channel for
Video input
16 16
16
Remark A:
1. Under 30fps, the recording channel can not be the multiple of 3, 5, and 9
2. At 60fps, the recording channel can not be the even multiple of 3, 5, and 9
3. 120fps recording under 16 channel
The channels are divided: (1、2、3、4) in one group / (5、6、7、8) in one group
(9、10、11、12) in one group / (13、14、15、16) in one group
As long as there is one input in either group, all the 4 channels will be recorded
Recording condition
