(5.) VIDEO MASK SETUP
**VIDEO MASK FUNCTION: ON / OFF
CH 01 : ON / OFF CH 09 : ON / OFF
CH 02 : ON / OFF CH 10 : ON / OFF
CH 03 : ON / OFF CH 11 : ON / OFF
CH 04 : ON / OFF CH 12 : ON / OFF
CH 05 : ON / OFF CH 13 : ON / OFF
CH 06 : ON / OFF CH 14 : ON / OFF
CH 07 : ON / OFF CH 15 : ON / OFF
CH 08 : ON / OFF CH 16 : ON / OFF
MASK means the channel would not display on the live screen, but still can set it on recording.
CAMERA SETUP
1. COLOR SETUP
2. TITLE SETUP
3. SCREEN POSITION SETUP
4. V-LOSS DISPLAY SETUP
5. VIDEO MASK SETUP
VIDEO MASK SETUP PAGE
**VIDEO MASK FUNCTION:
CH 01 CH 09
CH 02 CH 10
CH 03 CH 11
CH 04 CH 12
CH 05 CH 13
CH 06 CH 14
CH 07 CH 15
CH 08 CH 16
MENU, ESC: EXIT: : MODIFY
Press direction buttons up/down/left/right to choose items.
Press values change button to change values.
