Makita 2703 User Manual
Page 3
Item
Part
No.
No.
No.
Used
Description
Item
Part
No.
No.
No.
Used
Description
1
344536-2
1
Gear Housing Plate
2
911208-0
1
P.H. Screw M5x10
3
416340-0
2
Guide Bar Retainer
4
266040-0
4
Tapping Screw CT 4x25
5
323736-7
2
Guide Bar
6
159999-7
1
Gear Housing Com. (Includes
263005-3 - Rubber Pin 6 & 951157-9
- Spring Pin 5-16 & Item 21)
7
168313-6
1
Safety Guide (2702)(Includes
Torsion Spring 17- 231541-7,
Torsion Spring 17 - 231542-5, Hex
Bolt M6X50 -265462-1, Hex Nut
- 931302-2 & Flat Washer 6 -
941151-9 X 2)
168309-7
1
Safety Guide (2703)(Includes
Torsion Spring 17- 231541-7,
Torsion Spring 17 - 231542-5, Hex
Bolt M6X50 -265462-1, Hex Nut
- 931302-2 & Flat Washer 6 -
941151-9 X 2)
8
265391-8
2
(+) Hex Bolt M6x16
9
165206-8
1
Stay
10
911383-2
4
P.H. Screw M6x60
11
344545-1
1
Pressure Plate
12
921431-9
2
Hex Bolt M8x20
13
265995-6
2
Tapping Screw 4x18
14
687054-0
1
Strain Relief
15
416341-8
1
Cover
16
265995-6
2
Tapping Screw 4X18
17
266040-0
4
Tapping Screw CT 4x25
18
416340-0
2
Guide Bar Retainer
19
266040-0
2
Tapping Screw CT 4x25
20
961016-9
1
Stop Ring E-10
21
212121-8
1
Needle Bearing 1210
22
226499-3
1
Helical Gear 42
23
267176-8
1
Flat Washer 17
24
267170-0
1
Flat Washer 34
25
211256-2
1
Ball Bearing 6203LLB
26
316933-2
1
Bearing Box
27
153264-6
1
Spindle Com. (Includes 323738-3
- Spindle & Items 22-25)
28
224333-1
1
Flange 53
30
224347-0
1
Outer Flange 53
31
252155-9
1
Hex Nut M12-19
32
911233-1
4
P.H. Screw M5x20
33
322968-3
1
Screw Bar
34
416339-5
1
Screw Bar Retainer
35
941302-4
1
Flat Washer 12
36
951116-3
1
Spring Pin 4-20
37
226747-0
1
Straight Bevel Gear
38
253024-7
1
Flat Washer 10
39
231315-6
1
Compression Spring 14
40
322967-5
1
Lock Lever Shaft
41
922243-3
1
Hex Socket Head Bolt M5x25
42
272237-1
1
Lever 90
43
266034-5
2
Tapping Screw CT 4x16
44
253143-9
1
Flat Washer 12
45
213107-5
1
O Ring 12
46
214114-1
1
Plane Bearing 12
47
344544-3
1
Stay
48
344543-5
1
Pointer
49
922103-9
1
Hex Socket Head Bolt M4x6
50
951116-3
1
Spring Pin 4-20
51
911218-7
1
P.H. Screw M5x14
52
268031-7
1
Pin 8
53
271408-7
1
Knob 20
54
271071-6
1
Handle 120
55
323735-9
1
Handle Shaft
56
344581-7
1
Cap 92
57
271070-8
1
Handle 100
58
226747-0
1
Straight Bevel Gear
59
951116-3
1
Spring Pin 4-20
60
941302-4
1
Flat Washer 12
61
931502-4
1
Hex Nut M10
62
213423-5
1
O Ring 30
63
253792-2
1
Flat Washer 26
64
211206-7
1
Ball Bearing 6202LLB
65
253147-1
1
Flat Washer 15
66
240003-4
1
Fan 80
67
516761-7
1
Armature Assy (Includes 64-66,
68 & 69)
68
681640-9
1
Insulation Washer
69
211061-7
1
Ball Bearing 6000LLB
70
416331-1
1
Baffle Plate
71
266029-8
2
Tapping Screw Flange PT5x65
72
596181-1
1
Field Assy (Includes Items 123 & 124)
73
159998-9
1
Motor Housing Com. (Includes
2 X 643660-1 - Brush Holder 6.5-13.5)
74
181047-4
2
Carbon Brush CB-154 (2pcs/Set)
75
643650-4
2
Brush Holder Cap 6.5-13.5
76
266034-5
2
Tapping Screw CT 4x16
77
416439-1
1
Dust Guide
78
317382-6
1
Frame
*
(Old 316931-6)
79
344519-2
1
Frame Cover
80
266035-3
4
Tapping Screw Bind CT 5x12
81
344529-9
2
Slide Seat
82
251308-7
1
(+) P.H. Screw M4x10
83
687049-3
1
Strain Relief
84
911208-0
2
P.H. Screw M5x10
85
416333-7
1
Rack Plate
86
344518-4
1
Plate
87
911323-0
2
P.H. Screw M6x16
88
317010-3
1
Adjust Block
89
265460-5
2
Hex Bolt M6x20
90
232174-1
2
Leaf Spring
91
416332-9
2
Frame Retainer
92
911333-7
4
P.H. Screw M6x20
93
231240-1
1
Compression Spring 7
94
416375-1
1
Cap
95
664080-6
1
Cord #14-3-0.86
96
687054-0
1
Strain Relief
97
265995-6
2
Tapping Screw 4x18
98
416335-3
1
Switch Box
99
265995-6
2
Tapping Screw 4x18
100
687052-4
1
Strain Relief
101
416334-5
1
Switch Base
102
651567-7
1
Switch
103
416377-7
1
Slide Pin
104
416376-9
1
Switch Button
105
265999-8
3
Tapping Screw, Flange 4x25
106
344547-7
1
Plate
107
911323-0
2
P.H. Screw M6x16
108
316934-0
1
Center Cover (2702)
316935-8
1
Center Cover (2703)
109
816332-3
1
Scale Plate L
110
251308-7
2
(+) P.H. Screw M4x10
111
816331-5
1
Scale Plate R
112
251308-7
2
(+) P.H. Screw M4x10
3 Model 2702
3 Model 2703
