3. Network Functions

3.3 Projector Management using SNMP

The SNMP (Simple Network Management Protocol) enables to manage the
projector information, which is a failure or warning status, from the computer on
the network. The SNMP management software will be required on the computer
to use this function.

• It is recommended that SNMP functions be carried out by a network

administrator.
• SNMP management software must be installed on the computer to monitor
the projector via SNMP.

NOTE

SNMP Settings (

18)

Conﬁgure the following items via a web browser to use SNMP.

Example: If the IP address of the projector is set to 192.168.1.10:
1) Enter “http://192.168.1.10/” into the address bar of the web browser.
2) Enter the Administrator ID and Password and click [Logon].
3) Click [Port Settings] on the main menu.
4) Click [Enable] check box to open the SNMP Port. Set the IP address to send

the SNMP trap to when a Failure/Warning occurs.

5) Click [Security Settings] on the main menu.
6) Click [SNMP] and set the community name on the screen that is displayed.

7) Conﬁgure the settings for Trap transmission of Failures/Warnings. Click

[Alert Settings] on the main menu and select the Failure/Warning item to be
conﬁgured.

8) Click [Enable] check box to send out the SNMP trap for Failures/Warnings.

Clear [Enable] check box when SNMP trap transmission is not required.

9) Click [Apply] button to save the settings.

• A Network Restart is required after the Community name has been

changed. Click [Network Restart] and conﬁgure the following items.

NOTE

• A Network Restart is required after the SNMP Port conﬁguration

settings have been changed. Click [Network Restart] and conﬁgure the
following items.

NOTE
