29
3. Network Functions
3.1 Configuring and controlling the projector via a web browser (continued)
Item Description
Aspect Selects the aspect setting.
Over Scan Adjusts the over scan setting.
V Position Adjusts the vertical position.
H Position Adjusts the horizontal position.
H Phase Adjusts the horizontal phase.
H Size Adjusts the horizontal size.
Auto Adjust Execute Performs the automatic adjustment.
Input
Progressive Selects the progressive setting.
Video NR Selects the video noise reduction setting.
Color Space Selects the color space.
S-Video Format Selects the s-video format setting.
C-Video Format Selects the video format setting.
HDMI Format Selects the HDMI format setting.
HDMI Range Selects the HDMI range setting.
Computer in1 Selects the COMPUTER IN1 input signal type.
Computer in2 Selects the COMPUTER IN2 input signal type.
Frame Lock -
Computer in1
Turns the FRAME LOCK-COMPUTER IN1 function on/off.
Frame Lock -
Computer in2
Turns the FRAME LOCK-COMPUTER IN2 function on/off.
Frame Lock - HDMI Turns the FRAME LOCK-HDMI function on/off.
Setup
D-Zoom Adjusts the zoom.
D-SHIFT V Adjusts the vertical picture position.
D-SHIFT H Adjusts the horizontal picture position.
Picture Position Selects the vertical picture position.
Keystone V Adjusts the vertical keystone distortion setting.
Eco Mode Selects the eco mode.
Mirror Selects the mirror status.
Standby Mode Selects the Standby mode.
Monitor Out -
Computer in1 Assigns the MONITOR OUT when the COMPUTER IN1 input
port is selected.
Monitor Out -
Computer in2 Assigns the MONITOR OUT when the COMPUTER IN2 input
port is selected.
Monitor Out - HDMI Assigns the MONITOR OUT when the HDMI input port is selected.
Monitor Out - S-Video
Assigns the MONITOR OUT when the S-VIDEO input port is
selected.
Monitor Out - Video
Assigns the MONITOR OUT when the VIDEO input port is
selected.
Monitor Out - Standby Assigns the MONITOR OUT in the standby mode.
