McCulloch MCC4516FK - Manual (Page 3)

16" Electric Chain Saw
7/27/2009
No. Parts No. Description Q P Code
MCC4516FK
PARTS LIST
36 6SQABB04-20 SCREW 1 100
37 6181-211501 CLUTCH 1 100
38 6181-211502 CLUTCH 1 100
39 6024-211503 SPRING 1 100
40 6014-211501 WASHER 1 100
41 6154-211301 CONNECTING BAR 1 100
42 6SQABB4.5-30 SCREW 1 100
43 6154-211504 CONNECTOR 1 100
44 6017-211503 FRONT-HAND GUARD 1 100
45 6228-211303 FIXED ASS'Y 1 100
46 6SDABB04-16 SCREW 2 100
47 6079-211503 SPRING 1 100
48 6038-211504 HOUSING (L) 1 100
49 6086-211501 FRONT HANDLE COVER 1 100
50 6228-211401 MOTOR GEAR BOX ASS'Y 1 100
51 6022-211501 SWITCH 1 100
52 6SDABB04-10 SCREW 8 100
53 6011-211502 POWER CORD 1 100
54 6043-840001 STRAIN RELIEF 1 100
55 6059-855001 CORD GUARD 1 100
56 6012-211501 RUBBER STOP 1 100
57 6024-211506 SPRING 1 100
58 6PC05-14.7 PIN 1 100
59 6PC4.4-35 PIN 1 100
60 6SQAB-04-06 SCREW 1 100
61 6WFB-03-12 WASHER 1 100
62 6SDABB03-15 SCREW 1 100
63 6158-211502 PLATE 1 100
64 6SLABB03-06 SCREW 2 100
65 6010-211301 WIRE 1 100
66 6SDABB04-14 SCREW 2 100
67 6120-211401 CARRY CASE 1 100
