Makita LS0711Z - Manual (Page 2)

2
SPECIFICATIONS
Blade diameter ........................................................................................... 190 mm (7-1/2”)
Hole (arbor) diameter ................................................................................. 15.88 mm (5/8”)
Max. Miter angle ......................................................................................Left 47°, Right 57°
Max. Bevel angle ......................................................................................................Left 45°
Max. Cutting capacities (H x W) with blade 190 mm (7 - 1/2”) in diameter.
No load speed (RPM) .......................................................................................... 6,000/min.
Dimensions (L x W x H) ........................550 mm x 430 mm x 458 mm (21-5/8” x 17” x 18”)
Net weight ................................................................................................. 10.5 kg (23.2 lbs)
(Note)
* mark indicates that a wood facing with the following thickness is used.
1. When using a wood facing 20 mm (13/16”) thick.
2. When using a wood facing 15 mm (9/16”) thick.
• Manufacturer reserves the right to change specifications without notice.
• Specifications may differ from country to country.
Miter angle
Bevel angle
0° 45° (left)
0°
* 60 mm x 150 mm
(2-3/8” x 5-7/8”) Note 1
50 mm x 182 mm
(2” x 7-1/8”)
* 45 mm x 145 mm
(1-3/4” x 5-3/4”) Note 1
35 mm x 182 mm
(1-3/8” x 7-1/8”)
45° (left and right)
* 60 mm x 100 mm
(2-3/8” x 3-15/16”) Note 2
50 mm x 127 mm
(2” x 5”)
* 45 mm x 100 mm
(1-3/4” x 3-15/16”) Note 2
35 mm x 127 mm
(1-3/8” x 5”)
