APPENDIX B: XR2000 Configuration Settings
Table B-1: MultiView XR2000 Configuration Jumper Settings
Configuration Option (all options utilize
4th pair):
JP2 JP3 JP6 JP7 JP8 JP14 JP15 JP13 JP16 JP17
RGBHV Computer Video (see note below on daisy chaining)
With Left/Right Line Level Audio
1-2
1-2 1-2 1-2
3-4
5-6
out
out
1-2
IN
IN
With SDPIF Digital Audio
1-2
1-2 1-2 1-2 3-4
IN
out
1-2
IN
IN
With Simplex Serial (receive only)
1-2
1-2 1-2 1-2 1-2
out
IN
1-2
IN
IN
With Composite Video
1-2
1-2 1-2 1-2 3-4
IN
out
1-2
IN
IN
With serial or SA/SAP series
(requires separate daughterboard
installed)
2-3
2-3 2-3 2-3 out
out
out
1-2
out
out
Composite, S-Video, Component Video (see note below on daisy chaining)
With Left/Right Line Level Audio
1-2
1-2 1-2 1-2
3-4
5-6
out
out
2-3
IN
IN
With SDPIF Digital Audio
1-2
1-2 1-2 1-2 3-4
IN
out
2-3
IN
IN
With Simplex Serial (receive only)
1-2
1-2 1-2 1-2 1-2
out
IN
2-3
IN
IN
With Composite Video
1-2
1-2 1-2 1-2 3-4
IN
out
2-3
IN
IN
With SA/SAP series (requires
separate daughterboard installed)
2-3
2-3 2-3 2-3 out
out
out
2-3
out
out
Dual Port Daisy Chain units
*Use configuration above, but
remove JP16 & JP17 (see last unit
note below).
*
*
*
*
*
*
*
*
OUT OUT
For DP versions, the last unit in chain
requires JP16, JP17 IN except if units
are SA, or SAP versions.
*
*
*
*
*
*
*
*
IN
IN
