Mega Catch Premier MCP800 - Manual (Page 25)

23
Parts List
U .S . D e s ig n P ate n t N o 449,091 U.S.DesignPatentNo449,091
2
3
4
5
1
18
16
15
14
12
11
6
7
8
13
10
9
2
19
16 17
18
15
14
11
20
Description Part No.
Cross-section, side profile
1. Mega-Catch™ Premier Mosquito
Trap MCP-800
2. Programmable Timer MC-P01
3. Key MC-PU208
4. Lockable Door MC-PU203
5. External Skirt MC-PU112
6. Power Connection
7. Control Box MC-PU05
8. Top Plate MC-PU205
9. Light emitting Diodes
10. Internal Power Plugs
11. UV Tube MC-PU2
12. Reflective Surface MC-PU211
13. Bottom Plate MC-PU206
14. Fan Unit MC-PU210
15. Fan Safety Guard MC-PU209
16. Catch Bag MC-PU111
17. Liquid Catch Container MC-PU204
18. Octenol Fragrance Strip MC-PU224
19. 60ft Extension Cord MC-PU7
20. Transformer MC-P20
