UV Bulb

Turn to remove

Top Plate

Light fittings

Bottom plate

mounts into

lower slot in body

Top plate

mounts into

top slot in body

Fan cable plugs into 2 pin

socket on underside of top plate

Power cable

plugs into Control Box

Timer cable

plugs into

Control Box

U.V. cable plugs into

3 pin socket on

underside of top plate

Control Box

Heater cable plugs into 2 pin

socket on underside of top plate

FIG. 8.2 – Replacement of U.V. bulb

FIG. 8.1 – Opening the PREMIER Trap
