7
CAUTION:
• If you peel off the abrasive disc from the pad, its
adhesion will become poor. Never attempt to stick it onto
the pad for further use.
Installing dust bag
Install the dust bag on the tool so that the Makita logo on the
dust bag will be upright (not upside down). The dust bag can
be swiveled 360°. Position the skirt so that the dust bag will
not interfere with your work.
Emptying dust bag
When the dust bag is about half full, switch off and unplug
the tool. Remove the dust bag from the tool. Then remove
the dust nozzle from the dust bag after unlocking the dust
nozzle by turning it slightly counterclockwise. Empty the dust
bag by tapping it lightly.
After emptying the dust bag, install the dust nozzle on the
dust bag. Turn the dust nozzle slightly clockwise to lock it in
place. Then install the dust bag on the tool as described in
“Installing dust bag”.
1. Skirt
2. Dust bag
1 2
003321
1. Dust nozzle
1
003323
1. Dust nozzle
1
003326
