S

TANDS

Flex Stand Components (PN 46-00709)

Item

Item Description

Qty.

A Cradle

Coupler

1

B Cradle

1

C Flexible

Shaft

1

D Screw

Cap

2

E Stand

Base

1

F

¼" - 20 x ⅜" Flat Head Phillips Screw, 100° Undercut

2

G

#8 Round Head Wood Screw

2

H

M3 -.5 x 20 mm, Pan Head Phillips Screw

1

J

M3 Flat Washer

1

K

M3 Split Lock Washer

1

L

Flexible Shaft Cover

1

Figure 12. Stand Components
