Install 3 x 40 watt candelabra bulbs.
40
Install ornate lower cover and glass
onto light kit.
41
Install center plug by turning in
direction of arrow till tight.
42
Install blade and blade holder
assembly to fan motor using the pre-
installed screws,washers and motor
pads. Repeat this process 4 more
times until all blades are installed to
the fan.
31
Loosen 2 screws and remove 1
screw.
33
Install center plug by turning in
direction of arrow.
35
Place over the 2 screws and twist in
direction of arrow to hold in place.
Replace screw removed and tighen
all 3 screws securely.
34
Loosen 2 screws with key slots and
remove 1 screw without key slot.
Place upper cover light kit over 2
screws and twist in direction of arrow
to hold in place. Replace screw
removed and tighten all 3 securely.
36
Plug white wire from fan to white
wire from light kit. Then plug black
wire from fan to black wire from light
kit.
38
Loosen 3 screws with key hole slots.
37
Place light kit over 3 screws and
twist in direction of arrow to hold in
place. Then tighten all 3 screws
securely.
39
If not using light kit go to step 33.
If using light kit go to step 36.
32
At this point
you need to
decide if you
are using the
light kit or not.
