Miele S 7000 - Manual (Page 30)

If there are large particles or other
blockages at the base of the suction
hose, you can open it up to clear the
passage.
^ Click the vacuum cleaner into the full
upright position.
^ Press the release button on the
telescopic wand and remove the
handle from the suction hose
^ Guide the swivel elbow at the end of
the suction hose over the catch
hooks, to increase the stability the
vacuum cleaner.
A Undo the suction hose in the
direction of the arrow.
B Pull the suction hose connector off
the swivel elbow.
^ Remove all blockages
^ Put the connector back on and click
it shut.
If you still have not been able to remove
the obstruction(s), there is another
method you can try.
Open the service flap on the bottom
rear of the vacuum cleaner.
A Use a coin to undo the two screws
until they stop.
B Pry the service flap free.
^ Remove all blockages.
^ Put the service flap back on and
screw into place.
Maintenance and care
30
