Sample calculations for a countertop cut-out for three appliances
A
appliance width
minus 5/16"
(8 mm)
B
appliance width
C
appliance width
minus 5/16"
(8 mm)
D
Countertop
cut-out
11" (280 mm) 11 5/16" (288 mm) 11" (280 mm) 33 3/8" (848 mm)
11" (280 mm) 15" (380 mm) 14 5/8" (372 mm) 40 5/8" (1032 mm)
11" (280 mm) 22 11/16" (576 mm) 22 3/8" (568 mm) 56 1/16" (1424 mm)
14 5/8" (372 mm) 11 5/16" (288 mm) 11" (280 mm) 37" (940 mm)
14 5/8" (372 mm) 15" (380 mm) 14 5/8" (372 mm) 44 1/4" (1124 mm)
14 5/8" (372 mm) 22 11/16" (576 mm) 22 3/8' (568 mm) 59 11/16" (1516 mm)
22 3/8" (568 mm) 11 5/16" (288 mm) 11" (280 mm) 44 3/4" (1136 mm)
22 3/8" (568 mm) 15" (380 mm) 14 5/8" (372 mm) 52" (1320 mm)
22 3/8" (568 mm) - 22 3/8" (568 mm) 44 3/4" (1136 mm)
Installation
