31
All Models - Base Electrical Components
Item Part Description Qty.
No. No.
1* 0512108 THERMOSTAT, BOOSTER 1
(Beginning with S/N W14236 and above)
(501HT, 401HT, 201HT)
1 109069 THERMOSTAT, BOOSTER 1
(Prior to S/N W14236)
(501HT, 401HT, 201HT)
2 0507323 THERMOSTAT, WASH TANK 1
(All S/N's)
(501HT, 401HT, 201HT)
3 0501373 SWITCH, 3-POSITION TOGGLE 1
(501HT, 401HT, 201HT)
4 100007 SCREW, TRUSS SLOT SS 10-32 X 3/8 4
5 112518 CONTACTOR, 2-POLE 120V 1
(Prior to S/N W14236)
(501HT, 401HT, 201HT)
5 0512432 CONTACTOR, 3-POLE 120V 1
(Beginning with to S/N W14236 and above)
(501HT, 401HT, 201HT)
6 0312173-1 BRACKET, CHEMICAL PUMP, THERMOSTAT 1
(501HT, 401HT, 201HT)
7 0504822 SCREW, 8-32 X 1/2 PAN HD PH SST 8
8 0501450 SCREW, NIBS RH 6-32 X 3/16 PHIL.SS 4
9 0512444 LABEL, RINSE-WASH, BSTR. FILL 1
(501HT, 401HT, 201HT)
10 0312173-3 BRACKET, CHEMICAL PUMP, THERMOSTAT 1
(501LT, 201LT)
* P/N 109069 can be used an alternative replacement part beginning with S/N W14478
