23 Momentum mo8me Manual
The Tweak: Overview and Setup Chapter 4
Setting the Routing
Soft Key Description
Bk/Light Has two functions - 1) Sets the time-out 2) Adjust back light to high or low
setting (Page 26)
DFLT Mix Used to assign the Tweak to only operate one mix (Page 25)
mo8me Connects the Tweak to the appropriate mo8me (Page 24)
32ch MD Switches between 16 channel and 32 channel mode
Routing Allows user to select any 16 input channels from the Network (Page 23)
St/Mono Switches outputs between mono and stereo mode (Page 24)
My ID Sets the Tweak ID to 1-99 (Page 26)
Password If password is enabled, the Setup menu will not be accessible with out the
password (Page 27)
Press encoder until Mix Master Menu comes up •
Press • SETUP soft key
Press • ROUTING soft key on Setup Menu to view Routing screen
The Tweak is shipped with factory default routing of Network channels 1-32 •
Use the • PREV CH / NEXT CH soft keys to select channels 1-16 from the mo8me;
mo8me channels be displayed as MO8ME CH: XX
Turn encoder to select 32 input channels from the 256 Network channels. Network channels are •
displayed as ROUTED FROM: SNAKE CH: XX. Each network channel will correspond
to a specifi c mo8me channel; For example; mo8me Ch: 1 = Snake Ch: 5, mo8me Ch: 2 =
Snake Ch: 8, mo8me Ch: 3 = Snake Ch: 12 and so on to mo8me ch: 32
Press • SET ROUTE to set each route
• SUCCESS! will appear to indicate the selected route has been saved
Network channel routes are global to all eight output channels •
Press • EXIT to return to Setup Menu
Description of Setup Menu
