Specifications
Standards
IEEE802.3 10Base-T
Network Interface and Cable Specifications
RJ-45 ports for use with 10Base-T cabling
Maximum Segment Lengths
10Base-T (UTP) 100 meters maximum
Indicators
Power LED
Collision LED
Link/activity per port
Physical Dimensions
4-port hub: 100.5 mm x 78 mm x 27 mm
8-port hub: 153 mm x 78 mm x 27 mm
Environment
Operating temperature: 0°C to +40°C
Storage: -20°C to +70°C
7
LED
Power
Collision
Link/activity COLOR
Green
Amber
Green STATUS
On
On
On DESCRIPTION
Power is on
Collision is detected
The 10 Mbps
link pulse is
detected
There is activity
on the segment
Green Flashing
The table below lists the status and descriptions of
the LED's.
