2
SPECIFICATIONS
• Manufacturer reserves the right to change specifications without notice.
• Specifications may differ from country to country.
GENERAL SAFETY RULES
USA003-1
(FOR All BATTERY OPERATED TOOLS)
WARNING:
Read and understand all instructions. Failure to follow all
instructions listed below, may result in electric shock, fire and/or
serious personal injury.
SAVE THESE INSTRUCTIONS
Work Area 1. Keep your work area clean and well lit.
Cluttered benches and dark areas invite acci-
dents.
MODEL BSS730
Blade diameter 185 mm (7-1/4”)
Max. Cutting depth
at 90° 64 mm (2-1/2”)
at 45° 45 mm (1-3/4”)
at 50° 41 mm (1-5/8”)
No load speed (RPM) 2,400/min.
Overall length 375 mm (14-3/4”)
Net weight 4.0 kg (8.8 lbs)
Battery Charger DC24SA
Input A. C. only 50 Hz - 60 Hz
Output D. C. 7.2 V - 12 V
Battery Cartridge B2417 B2430
Voltage 24 V
Charging time 30 min. 60 min.
