Default 120VAC (User selectable at 120/127VAC)
2-4 years, depending on discharge cycles and ambient temp
550VA/330W 750VA/450W
500 J
0 ns (instantaneous) normal mode; <5 ns common mode
<5%
Normal and common mode EMI/RFI suppression
1-12V7Ah 2-12V7Ah
Audible noise at 1 m (3 ft.)
Electromagnetic immunity
<45 dBA
Runtime: Full Load
IEC 801-2 level IV, 801-4 level IV, 801 -5 level III
Runtime: Half Load
10 Base-T surge protection let-
through (as a percentage of
an applied +/-6 kV 1.2/50 us,
500 a 8/20 uS test)
Telephone line surge protec-
tion let-through (as a percent-
age of an applied +/-6 kV 1.2/
50 us, 500a 8/20 uS test)
Typical recharge time
Typical battery life
Battery type: Sealed, non-
spillable, maintenance free,
lead-acid
<1%
<5%
8 hours from total discharge
Noise filter
Surge voltage let-through (as
a percentage of an applied
ANSI C62.41 Cat. A +/-6 kV)
Surge response time
Surge current capability
(one time, 8/20 uS waveform)
6500 Amps total
Surge energy rating (one time,
10/1000 uS waveform)
Protection
On-battery waveshape
Over current, short circuit protected and latching shutdown
Simulated Sine Wave
On-battery frequency 50/60 Hz, +/-.5 Hz, unless synchronized to utility
On-battery output voltage
Maximum load
2-6 mS typical
50 or 60 Hz, +/-6Hz
Resettable circuit breaker
50 or 60 Hz, autosensing
0 - 150VAC
120VAC setting (default):85-132VAC, Selectable: 75/80-132VAC
127VAC setting: 85-140VAC, Selectable: 75/80-140VAC
120VAC setting: 105-132VAC, 127VAC setting: 105-140V
Transfer time
Frequency limits (AC Mode)
Input protection
Nominal input frequency
Output voltage (AC Mode)
Input voltage (AC Mode)
Acceptable Input voltage
MBK750E MBK550E MODEL NUMBER
7.56 x 12.56 x 6.38"
192 x 319 x 162 mm
18.74 (22)lb
8.5 (9.7)Kg 25.8 (29)lb
11.7 (12.9)Kg
Weight - Net (Shipping)
Size - Net
H X D X W
UL1778, cUL (CSA 22.1)
FCC Class B, CE certified
Safety and approvals
EMC Verification
13 x 18.9 x 11.4"
330 x 480 x 290 mm Size - Shipping
H X D X W
11-Minutes 19-Minutes
5-Minutes 3-Minutes
