Magnadyne M9800 - Manual (Page 6)

Installation Procedure
Left Front
Speaker
Left Rear
Speaker
+ -
Green Wire
Orange Wire 12 VDC Constant
Green/Black Wire
Black/Green Wire
Green/Red Wire
Right Rear
Speaker
Right Front
Speaker
+ -
+ -
+ -
Gray Wire
Black/Gray Wire
Gray/Black Wire
Gray/Red Wire
Red Wire 12 VDC Ign./Acc. Lead
Black Wire 12 VDC Ground
12
11
10
9
8
7
6
5
4
3
2
1
3A
Four Speaker Wiring
Left Front Speaker
+ -
Green Wire
Orange Wire 12 VDC Constant
Green/Black Wire
Black/Green Wire
Green/Red Wire
Right Front Speaker
Tape
Ends
+ -
Gray Wire
Black/Gray Wire
Gray/Black Wire
Gray/Red Wire
Red Wire 12 VDC Ign./Acc. Lead
Black Wire 12 VDC Ground
3A
Two Speaker Wiring
12
11
10
9
8
7
6
5
4
3
2
1
6
