Makita HR4511C - Manual (Page 2)

Principle of
Dynamic Vibration Absorber
Reinforcing bar Reinforcing bar Reinforcing bar
Piston
Striker
Sleeve
Air
Striker
Piston
THE MOTHER EARTH SOMETIMES QUAKES.
Time to reach ELV
Slide Chuck
:: push-in and Go
:: slide-back and Pull
Electronic control features
Variable speed control by dial Constant speed
control, Soft Start variable speed control
LED lamp
for indication of "Green"
:: being electrified of
"Blinking Red"
:: replacing of carbon brush
No Hammering
while Idling
ensures machine's long life.
Torque Limiter
when drill bit hits against
reinforcements,
Torque Limiter operates
to stop.
Change Lever
in protected position
for reduced possibility of
breakage even if the machine
is carelessly down to rest.
HR4511C
HR4510C
HR4501C
/// Active Dynamic Vibration Absorber
/// Active Dynamic Vibration Absorber
/// Vibration Absorbing Grip
Learned
from
the
Mother Earth
MAKITA's
"Active" Dynamic
Vibration Absorber
(HR4511C and HR4510C)
Extremely Comfortable
Easy and Very Comfortable
Easy and Comfortable
Easier to manage the exposure of vibration to body.
Easy operating Slide Lock-on Switch for hammering.
Easiest to manage the exposure of vibration to hands and arms.
Slide Lock-on switch leaves operators' fingers out of effort
to keep pulling trigger for long hours when hammering.
Selectable Switches
Hammering
Hammering
Hammering
with Rotation
Hammering
with Rotation
Vibration Absorbing Grip
(HR4511C only)
Spring
Hinge
Piston
Balancer
Air
Piston
Balancer
Air
Air
Air
Slide lock-on switch
for Hammering
Trigger switch for
Hammering and
Hammering with Rotation
Tool does not come with bit.
Tool does not come with bit.
Tool does not come with bit.
Shift of air pressure in crank room
and barrel room "actively"
controls balancer to move
opposite of piston.
Spring loaded
hinged grip absorbs vibration
16 Angle Settings
of Chisel bit
20 m/s 2 15 m/s 2
150min 200min 100min
213 min
133 min
47 min
37 min
42 min
37 min
53 min
50min
10 m/s 2
HR4511C
HR4510C
HR4501C
Competitor "H"
Competitor "B"
Competitor "D"
HR4500C
Comparison of Vibration level* and Time to reach
ELV (Exposure Limit of Vibration)**
*It is known as the tri-axial value and value at Directive of A(8).
**It means the maximum amount of vibration that an operator may be exposed to on any single day.
Vibration level
See the Result of AVT
Longer life of Carbon brushes
features twice as long as that of Predecessor
model by employing large carbon brush.
Auto Cut-Out
Carbon Brush
protects commutator and
indicates time for
maintenance.
Rubberized Soft Grip
provides more control and
comfort while minimizing
hand fatigue and pain.
How to generate POWER
How to manage VIBRATION
How to bring you COMFORT
7.5 m/s 2
9.5 m/s 2
16 m/s 2
18.0 m/s 2
17.0 m/s 2
18.0 m/s 2
15.0 m/s 2
