4 Model LS1040

Item No.

Description

Type 1

Type 2

76

Spring Holder

343638-1

344464-1

77

Pin 8

256199-1

256280-8

78

Sleeve 8

257681-3

- - - - -

Above parts are completely interchangeable as a set.

SERVICE CHANGES

1. Change on Style of Spring Holder and Pin 8.

Item

Part

No.

No.

No.

Used

Description

Item

Part

No.

No.

No.

Used Description

88

416001-2

1

Kerf Board

89

416001-2

1

Kerf Board

90

921452-1

1

Hex Bolt M8x30

91

931402-8

1

Hex Nut M8

92

252105-4

1

Hex Lock Nut M8-13

93

253762-1

1

Flat Washer 8 (Old 253852-0)

94

931402-8

1

Hex Nut M8

95

921452-1

1

Hex Bolt M8x30

96

816310-3

1

Scale Label

97

816311-1

1

Bevel Scale Plate

98

251896-4

2

Screw M5X20

99

251887-5

1

Screw M6X10

103

687080-9

2

Field Clamp

104

251887-5

2

Screw M6X10

105

265917-6

2

Adjust Bolt M8X42

106

251370-2

1

(+) P.H. Screw M5

107

251887-5

1

Screw M6X10

108

253804-1

1

Flat Washer 6

109

271286-5

1

Knob 40

110

316938-2

1

Vise Arm

111

322313-2

1

Vise Rod

112

343651-9

1

Vise Plate

123

253047-5

1

Flat Washer 6

124

253744-3

1

Flat Washer 12

125

271275-0

1

Knob 45

126

315891-9

1

Vice Plate

127

321490-7

1

Release Nut R

128

321491-5

1

Release Nut L

129

341911-3

2

Protector

130

341912-1

1

Nut Holder

131

342967-9

1

Set Plate

132

911216-1

1

P.H. Screw M5x14

133

911317-5

1

P.H. Screw M6x14

200

654502-4

2

Solderless Connector(Old 654553-7)

201

654020-2

2

Garter Spring

202

654098-5

4

Receptacle

Accessories

A02

762001-3

1

Triangular Rule

A03

782212-4

1

Socket Wrench 13

A04

122523-9

1

Dust Bag Assy (Includes Item A05)

A05

410602-8

1

Fastener

A06

192622-1

1

Crown Molding Stopper Set

A07

193471-9

1

Sub Plate Assy (Old 122531-0)

A08

256812-1

2

Extension Rod

A09

192621-3

1

Holder Set(2pcs) (Includes Item 98)

A10

122472-0

1

Set Plate Assy (Includes Item 99)

A11

192713-8

1

Foot Assy (Includes Items 104 & 105)
(Old 122446-1)

A12

192625-5

1

Vertical Vise Assy (Silver)(Includes
Items 106 - 112) (Old 122468-1 - Beige)

A13

122563-7

1

Horizontal Vise Assy (Includes Items
123 - 133)(Old 122569-5 & 122567-9)

*

SEE SERVICE CHANGES
