3 Model LS1040

Item

Part

No.

No.

No.

Used Description

Item

Part

No.

No.

No.

Used

Description

1

416004-6

1

Handle Cover

2

211206-7

1

Ball Bearing 6202LLB

3

253853-8

1

Flat Washer 15

4

343641-2

1

Shaft Lock

5

241909-9

1

Fan 80

6

516716-2

1

Armature(Old 616716-3)

7

681640-9

1

Insulation Washer

8

211061-7

1

Ball Bearing 6000LLB

9

416002-0

1

Baffle Plate

10

636136-5

1

Field

11

265995-6

2

Tapping Screw 4x18

12

687052-4

1

Strain Relief

13

664463-0

1

Cord with Plug 2P-14-2.5

14

682505-8

1

Cord Guard 10-90

15

643660-1

2

Brush Holder 6.5-13.5

16

265995-6

5

Tapping Screw 4x18

17

911383-2

4

P.H. Screw M6x60

18

411478-6

1

Lock Off Button

19

643650-4

2

Brush Holder Cap 6.5-13.5

20

181047-4

2

Carbon Bush CB-154 (2pcs/set)

21

159916-7

1

Motor Housing Com.
(Includes Item15)

22

651923-1

1

Switch

23

231457-6

1

Compression Spring 3

24

416000-4

1

Lock Off Lever

25

415999-0

1

Switch Lever

26

414546-4

1

Cam

27

266029-8

2

Tapping Screw PT 5x65

28

231297-2

1

Compression Spring 9

29

251667-9

1

Hex Bolt M8x75

30

262511-5

1

Rubber Sleeve 6

31

265995-6

1

Tapping Screw 4x18

32

416007-0

1

Guide Cover

33

226465-0

1

Helical Gear 42

34

316821-3

1

Bearing Box

35

211256-2

1

Ball Bearing 6203LLB

36

285685-5

1

Bearing Retainer 64

37

322865-3

1

Spindle

38

224333-1

1

Flange 53

39

224333-1

1

Flange 53

40

265355-2

1

Hex Flange Head Bolt M8x20

41

343639-9

1

Center Plate

42

344380-7

1

Center Cover

43

265324-3

1

Hex Flange Head Bolt M8x12

44

231593-8

1

Torsion Spring 36

45

416003-8

1

Safety Cover

46

267136-0

1

Flat Washer 5

47

911213-7

1

P.H. Screw M5x12

48

265985-9

1

Hex Socket Head Bolt M6

49

911223-4

2

P.H. Screw M5x16

51

151461-8

1

Blade Case Com. (With 212121-8
Needle Bearing 1210)

52

265488-3

4

Hex Bolt M8x30 (Old 921451-3)

53

316826-3

1

Guide Rule

54

912342-9

1

Countersunk Head Screw M6x25

55

253715-0

1

Flat Washer 6

56

150663-3

1

Sub Fence Com.

57

344476-4

1

Sub Fence Plate

58

252014-7

1

Hex Lock Nut M6-10

59

251961-9

1

Hex Socket Head Bolt M6x10

60

257162-7

1

Ring 7

61

253823-7

1

Flat Washer 7

62

265984-1

1

Hex Socket Button Head Bolt M6

63

344377-6

1

Link Plate

64

265984-1

1

Hex Socket Button Head Bolt M6

65

253823-7

1

Flat Washer 7

66

257162-7

1

Ring 7

67

416006-2

1

Lever 100

68

911113-1

1

P. H. Screw M4x10

69

265437-0

1

Hex Bolt M10

70

253024-7

1

Flat Washer 10

71

256836-7

1

Rod 16

72

150664-1

1

Arm Com.(Includes Item 96)

73

322317-4

1

Stopper Pin

74

213021-5

1

O Ring 5

75

233152-4

1

Compression Spring 28

76

*

1

Spring Holder

77

*

1

Pin 8

78

257681-3

1

Sleeve 8

*

(Old)

79

911113-1

1

P.H. Screw M4x10

80

344385-7

1

Pointer

81

343799-7

3

Slide Plate

82

921452-1

1

Hex Bolt M8x30

83

911213-7

2

P.H. Screw M5x12

84

273495-2

1

Grip 32

85

344381-5

1

Knock Spring

86

150648-9

1

Base Com. (Includes Item 97)

87

316824-7

1

Turn Base

*

SEE SERVICE CHANGES
