Grizzly Model H5698 - Manual (Page 24)

-22-
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 X1713001 TABLE
2 X1713002 TABLE INSERT
3 X1713003 TABLE PIVOT BRACKET
4 XPSB48M CAP SCREW M6-1 X 35
5 XPW03M FLAT WASHER 6MM
6 XPS09M PHLP HD SCR M5-.8 X 10
7 XPLW01M LOCK WASHER 5MM
8 X1713008 TABLE PEDESTAL
9 XPB07M HEX BOLT M8-1.25 X 25
10 XPLW04M LOCK WASHER 8MM
11 XPS65M PHLP HD SCR M6-1 X 10
12 X1713012 SCALE INDICATOR
13 X1713013 MALE KNOB M6 X 14
14 X1713014 GRADUATED SCALE 0-45˚
15 X1713015 AIR HOSE POST
16 X1713016 BLADE GUARD
17 X1713017 AIR HOSE
18 XPS65M PHLP HD SCR M6-1. X 10
19 XPLW03M LOCK WASHER 6MM
20 XPW03M FLAT WASHER 6MM
21 X1713021 HOLD DOWN SHOE
22 XPS09M PHLP HD SCR M5-.8 X 10
23 X1713023 KNOB BOLT M6-1 X 13
24 X1713024 BLADE CLAMP
25 X1713025 UPPER BLADE GUIDE
26 X1713026 LOWER BLADE GUIDE
27 X1713027 SWITCH BOX HOUSING
28 X1713028 CIRCUIT BOARD
29 XPS02M PHLP HD SCR M4-.7 X 12
30 XPW05M FLAT WASHER 4MM
31 XPN09M HEX NUT M12-1.75
32 XPLW05M LOCK WASHER 12MM
33 X1713033 SWITCH BOX COVER
34 X1713034 LIGHT SWITCH
35 X1713035 SPEED CONTROL DIAL
36 XPHTEK7 TAP SCREW #8 X 3 ⁄
8
"
37 X1713037 POWER CORD
38 X1713038 BLADE TENSION ASSEMBLY
39 X1713039 UPPER ARM
40 X1713040 LOWER ARM
41 XPS75M PHLP HD SCR M5-.8 X 35
42 XPLW01M LOCK WASHER 5MM
43 X1713043 RIGHT ARM COVER
44 X1713044 LEFT ARM COVER
45 X1713045 BUSHING 3 ⁄
8
"
46 X1713046 MOTOR
46-1 X1713046-1 CARBON BRUSH
46-2 X1713046-2 CARBON BRUSH CAP
47
X1713047 FLYWHEEL
48 X1713048 LINK
49 XP625 BALL BEARING 625ZZ
50 X1713050 RETAINER
51 XPSB24M CAP SCREW M5-.8 X 16
52 XPLW01M LOCK WASHER 5MM
53 XPSB38M CAP SCREW M5-.8 X 25
54 XPW02M FLAT WASHER 5MM
55 XPLW02M LOCK WASHER 4MM
56 X1713056 SPACER 5MM ID X 6MM
57 XPN06M HEX NUT M5-.8
58 XPLW01M LOCK WASHER 5MM
59 X1713059 6 AMP FUSE
60 X1713060 BLADE TENSION SPRING
61 X1713061 FLEXIBLE NECK GUARD
62 X1713062 MOTOR CORD
63 X1713063 FLEXIBLE NECK
64 X1713064 LAMP HOUSING
65 X1713065 LAMP
66 X1713066 BULB
67 X1713067 CORD CLAMP
68 XPS07M PHLP HD SCR M4-.7 X 8
69 X1713069 BELLOWS
70 X1713070 BELLOWS LOCK
71 X1713071 PVC TUBE
72 X1713072 FORKED RETAINER
73 XPSB17M CAP SCREW M4-.7 X 10
74 XPS05M PHLP HD SCR M5-.8 X 8
75 X1713075 VARIABLE SPEED SWITCH
76 X1713076 THIN PROFILE HEX NUT 10MM
77 X1713077 BASE
78 XPCB13M CARRIAGE BOLT M6-1 X 20
79 XPLW03M LOCK WASHER 6MM
80 XPN01M HEX NUT M6-1
81 XPLW03M LOCK WASHER 6MM
82 XPB08M HEX BOLT M6-1 X 20
83 X1713083 STUD BOLT M6-1 X 95
84 XPN01M HEX NUT M6-1
85 X1713085 SPACER
86 X1713086 STUD BOLT HINGE PIN M6-1 X 18
87 XPS62M PHLP HD SCR M6-1 X 30
88 X1713088 BLADE GUIDE SPACER
