11. ND-100 SPECIFICATIONS
GPS Characteristics
GPS Chipset M-Star MSB2122
Frequency L1, 1575.42 MHz
C/A Code 1.023 MHz
Channels 48 channel all-in-view tracking
Sensitivity Tracking:-161dBm
GPS Antenna Type Built-in ceramic patch antenna (18 x 18 x 4mm)
Accuracy
Position Horizontal
< 5m 2D RMS WAAS/ EGNOS/ MSAS enabled (CEP with DGPS)
> 5m ~ 10m 2D RMS WAAS disabled (CEP without DGPS)
Velocity Velocity:0.1 m/s
Time 1ms RMS
WAAS/ EGNOS/ MSAS Enabled
Datum
Datum Default: WGS-84
Acquisition Rate
Hot start 1.5 sec., average
Warm start 32 sec., average
Cold start 34 sec., average
Reacquisition < 1 sec. average
Protocol
GPS Protocol
NMEA 0183 v3
GGA(1sec), GSA(1sec), GSV(5sec), RMC(1sec)
(VTG and GLL are optional)
GPS Transfer Rate 4800 (Bits per Second: 4800, Data bits: 8, parity: None, Stop bits:1)
GPS Update Rate 1 Hz
USB Protocol USB 2.0
Operating Systems
Windows 98 / 2000 / XP / Vista
Mac OSX 8&9 / 10.x
Linux RedHat 7.3 / 8.0 / 9.0
Dynamic Condition
Acceleration Limit Less than 4g
Altitude Limit 18,000 meters (60,000 feet) max.
Velocity Limit 515 meters/sec. (1,000 knots) max.
Temperature
Operating -4°~140°F (-20°~60°C)
Storage -22°~ 158°F (-30°~70°C)
Humidity Up to 95% non-condensing
Electrical Characteristics
Voltage DC 5.0V, USB bus power
Current < 55 mA
Power Consumption < 275 mW
Physical Characteristics
Dimension 2.6”L x 0.9”W x 0.4”H (65.5L x 23W x 11H mm)
Unit Weight 0.04 lbs (20g)
Certifications
FCC USA (Covers requirements for CANADA ICES-003)
CE Europe
