308532 21
Technical Data
Model 800707
Engine (4 cycle, air--cooled) 16 HP Briggs & Stratton OHV
Battery 12 Volt, 30 AMP
250 CCA
Gasoline Tank Capacity 2.25 Gallon (8.5 Liter)
Water Pump Maximum Working
Pressure
4000 psi (276 bar)
Water Pump Maximum Flow 4.25 gpm (16 lpm)
Inlet Hose Connection 3/4” garden hose (f)
Weight 255 lbs (116 kg)
Dimensions
Length
Width
Height
49” (1245 mm)
30” (762 mm)
30” (762 mm)
Maximum Inlet Water
Temperature
160 _ F (70 _ C)
Wetted Parts
High Pressure Hose
Bypass Hose
Pressure Washer
(including fittings)
Acrylonitrile and Buna--N cover and tube
Synthetic yarn and EPDM
Anodized aluminum, Aluminum or bronze alloys, Brass Copper, Nylon--PTFE composite,
PTFE, Ceramic, Buna--N, Cotton phenolic, 303, 304, and 316 Stainless steel, Polymide--12
thermoplastic, Carbon steel, Zinc with or without yellow chromate plate
