Magnum P62-Series Hardened Switches Installation and User Guide (12/02)
10
www GarrettCom com . .
The Magnum P62-5V models are available with an External Power Source (Optional)
for power input of universal AC power using the Magnum PSX-A unit. The 125/250 VDC
model (PSX-T) input power supports a range of 100-275VDC and comes with input safety
shield, fuses, and is diode-protected against accidental reverse polarity connection.
The AC Power Source, PSX-A, is equipped with a worldwide range of 85-264vac, 47-
63Hz and is auto-ranging with 5VDC 3Amp Power output. For both models, the military
style screw-lock plug provides a secure connection.
See Section 3.3 for detail description of the PSX-A and PSX-T external power sources.
2.2.2 Managed mP62 chassis with fiber SC (m.m. or single-mode) ports
Magnum mP62-5V
mP62-5V with the PSX-A = AC model
The Managed mP62 model is equipped with industry standard network management and
utility software operating features to make this Switch suitable to deploy in mission-critical
applications and in harsh environments. It also has internal components rated at 85`C so that
it can operate at higher (75`C) ambient temperatures than the P62F models.
The MNS-mP software supports managed edge-switch functions including menu-driven
user interface, SNMP, QoS, VLAN, STP, Port settings control, Password security, and
BootP / DHCP etc. The virtual LAN supports the Port based VLAN only and is easily setup
on the managed MP62 Switch to provide a secure and highly efficient network to its users.
The MENU driven MNS-mP CLI software is user friendly and easily operated by the
network user to configure the network as per their needs. The neat appearance of the MENU
driven MNS-mP is specially developed to have its function configured easily by the users.
