Radar Page Layout
This section describes the features of the Radar Page and how its features are displayed. By default, the Radar Page displays a Status Bar along
the top, user configurable Digital Navigation Data down the right side, a Heading Line, and Range Rings. Soft key options that allow quick
access to radar functions and setting changes are displayed along the bottom of the page.
Status bar
Range rings
Zoom scale
Ring separation
Digital
navigation
data
Soft key options
Heading line
GMR 21/41 O
PERATION
>
R
ADAR
P
AGE
L
AYOU
T
