Installation Preparation
PARTS PROVIDED
Locate the parts packed with the hood.
HARDWARE PACKAGE
Locate and check
contents. Screws
shown actual size.
2 Grease trays (3 with 54" hood)
Implement rods with standoffs
Duct collar
Support frame for 8 ft. ceiling
with 4 large pan head screws
installed on the bottom corners.
2-piece decorative duct cover
Transition with Damper
Decorative top cover
2 Filters (3 with 54" hood)
ACCESSORY PACKAGE
Check accessory package.
Select the taller set for 9’6 to 10’4" ceilings.
Select the shorter set for 8’6" to 9’6" ceilings.
Discard unused set.
