3. Attach two Base Pads (82) to the Base (108)
with two #8 x 1" Tek Screws (83) as shown.
Insert an Extension Leg (89) into the Base (108)
as shown. Hold two Extension Leg Nuts (67) in
the bottom of the Extension Leg. Next, insert
two 5/16" x 2 1/4" Bolts (65) into the top of the
Extension Leg, and firmly tighten the Bolts into
the Extension Leg Nuts.
3
89
82
82
108
83
65
67
4. With the help of a second person, carefully tip
the treadmill onto its other side. Partially fold the
Frame (58) so that the treadmill is more stable.
Do not fully fold the Frame yet.
Attach the Left Upright (84) to the Base (108)
with a 3/8" x 1" Bolt (106), a 3/8" x 2 3/4" Bolt
(105), and two 3/8" Star Washers (23).
Do not
tighten the Bolts yet.
4
108
58
84
106
23
105
7
2. Hold the Right Upright (107) against the Base
(108). Be careful not to pinch the Upright
Wire (77).
Attach the Right Upright (107) to the Base (108)
with a 3/8" x 1" Bolt (106), a 3/8" x 2 3/4" Bolt
(105), and two 3/8" Star Washers (23).
Do not
tighten the Bolts yet.
2
23
77
107
105
106
108
