Control Definitions
0
14 TFT Display The full-color TFT Display is a 8 inch display. The brightness, contrast, hue, and satura-
tion of the TFT Display can be adjusted in the DVD Setup Menu.
15 Infrared Receiver The Infrared Receiver receives signals sent from the remote control.
16 Power Indicator The Power Indicator lights when the unit is turned on.
17 Battery Compartment The Battery Compartment holds a Lithium Polymer Battery that powers the
unit when charged. The battery can be charged by plugging the unit into an AC or DC power source
using the included adapters.
18 Coaxial Audio Output Use the Coaxial Audio Output to play audio from the unit on a connected stereo
system. (Requires a Coaxial - .5MM Cable, not included)
19 S-Video Output Use the S-Video Output connection to send a higher quality standard video signal to
the TV. (Requires an S-Video - .5MM Cable, not included)
20 Audio & Video Output Use the Audio & Video Output to play audio or video from the unit on an
external system. (Requires an RCA - .5 MM Cable, not included)
21 Headphone Output 1 & 2 Use the Headphone Output 1 & to listen to the unit through a set of head-
phones. (Requires Headphones, one set included)
22 Charge Indicator The Charge Indicator blinks when the unit’s internal battery is being charged. The
Charge Indicator remains lit, without blinking, when the battery is fully charged.
23 Power Switch Adjust the Power Switch to turn the unit off and on.
24 DC Power Input (9V - 12V) Connect the DC Power Input to power the unit and charge the internal
battery. (AC Adapter & DC Car Adapter included)
25 USB Input Use the USB Input to connect a USB Thumb Drive to the unit. Media stored on the USB
Thumb Drive can be played on the unit by switching to USB mode.
26 SD/MMC Memory Card Slot The SD/MMC Memory Card Slot accepts SD and MMC memory card
formats. Media stored on a loaded memory card can be played on the unit by switching to SD mode.
• The unit will only play some mainstream audio, AVI, JPG, and JPEG formats from SD or MMC
Memory Cards.
