Completing the RAID BIOS Setup
After assigning your RAID array disks, press F7. The Clear disk data prompt appears.
Press Y if you want to wipe out all the data from the RAID array, otherwise press N. You must choose Yes if
the drives were previously used as RAID drives. The Array List window appears, where you can review the
RAID arrays that you have set up.
You can select a disk array as boot device if you want to boot operating system from an array. Use the arrow
keys to select the array, then press B to specify the array as bootable.
NVIDIA RAID Utility Jan 12 2005
- Define a New Array -
RAID Mode: Mirroring Striping Block: Optimal
Free Disks
Loc
Disk Model Name
Array Disks
Loc
Disk Model Name
[ ] Add
[ ] Del
[ESC] Quit [F6] Back [F7] Finish [TAB] Navigate [ ] Select [ENTER] Popup
1.0.M Maxtor 6Y080M0
1.1.M Maxtor 6Y080M0
Clear disk data ?
[Y] YES [N] NO
NVIDIA RAID Utility Jan 12 2005
- Array List -
[Ctrl-X] Exit [ ] Select [B] Set Boot [N] New Array [ENTER] Detail
Boot Id Status Vendor Array Model Name
Yes 2 Healthy NVIDIA MIRROR 76.33G
