Inventory
Figure 5. Main table saw unit.
Figure 7. Component inventory.
a
C
d
E
F
g
h
i
J
K
l
M N
o
p
Q
Figure 6. Extension wings.
B
Box Contents: (Figures 5–7) Qty
A. Main table saw unit .................................. 1
B. Extension Wings ........................................ 2
C. dust port .................................................... 1
D. door ............................................................ 1
E. Blade guard assembly .............................. 1
F. riving Knife ................................................ 1
G. Miter gauge ................................................ 1
h. Wrench 27mm ............................................ 1
I. Wrench 22/24mm ....................................... 1
J. dado table insert ....................................... 1
K. hex Wrench set (Eight pieces) 1.5-8mm ... 1
L. Key 5 x 5 x 40 ............................................ 1
M. handwheel lock Knob ............................... 1
N. handwheel handle ..................................... 1
O. handwheel ................................................. 1
p. push stick .................................................. 1
Q. saw Blade 10" x 40t .................................. 1
hardware (Not Shown) Qty
phillips head screw M6-1 x 12 (Mag switch) .... 1
hex Bolts M6-1 x 12 (Mag switch) .................... 2
lock Washers 6mm (Mag switch) ..................... 3
Flat Washers 6mm (Mag switch) ...................... 3
I]Z[daadl^c\^hVYZhXg^ei^dcd[i]ZbV^cXdbed"
cZcihh]^eeZYl^i]ndjgbVX]^cZ#AVni]ZXdbed"
cZcihdjiid^ckZcidgni]Zb#
>[ Vcn cdc"egdeg^ZiVgn eVgih VgZ b^hh^c\ Z#\# V
cjidgVlVh]Zg!lZl^aa\aVYangZeaVXZi]Zb0dg
[dgi]ZhV`Zd[ZmeZY^ZcXn!gZeaVXZbZcihXVcWZ
dWiV^cZYVindjgadXVa]VgYlVgZhidgZ#
NOTICE
If you cannot find an item on this list, check
the mounting location on the machine or the
packaging materials. Sometimes parts are
pre-installed for shipping, or they become
hidden by packaging materials.
