– 46 –
T e s t
Mode
Press Displays Exit
t01 Start/
Pause Displays UI model number (01-16) that corresponds to the UI model
the control is currently confi gured for. Always displays"---" when no
model is set in the control board. Proper model must be set when
control board replaced. Rotate knob until desired UI model number
is displayed (01-03), then press and hold Start/Pause until beep. Press Power
Returns to t01
t02 Start/
Pause Displays the most recent error code. Control will store 8 error codes
(E00=none). Press Start/Pause to clear each error code and display
the next. Press and hold Start/Pause to clear all error codes (will
then display E00). Press Power
Returns to t02
t03 Start/
Pause Displays software and non-volatile revision numbers. Presents
software revision number fi rst. Press and hold Start/Pause to select
non-volatile revision number. Press Power
Returns to t03
t04 Start/
Pause Non-volatile memory test. The control will compute and compare
the 16-bit CRC of the non-volatile memory with the pre-computed
16-bit CRC stored in the non-volatile memory. The control will sound
the key press beep and display "EEP" after successful comparison,
or sound the invalid key beep and display "Err" if unsuccessful. Press Power
Returns to t04
t05 Start/
Pause Turns on all LEDs and the 7-segment display. Press Power
Returns to t05
t06 Start/
Pause The control will sound a beep as long as any key is pressed. Press Power
Returns to t06
t07 Start/
Pause Turns on motor and inner coil (electric) or burner (gas). Displays
outlet thermistor temperature in degrees Fahrenheit. Press Power
Returns to t07
t08 Start/
Pause Turns on motor and inner coil (electric) or burner (gas). Displays inlet
thermistor temperature in degrees Fahrenheit. Press Power
Returns to t08
t09 Start/
Pause Displays voltage read from the moisture sensor in volts. Press Power
Returns to t09
t10 Start/
Pause Displays the condition of the exhaust system. The test takes
approximately 2 minutes to complete. The control measures
the rate of temperature increase through the inlet thermistor
for a duration of 30 seconds. An acceptable increase is 48°F
(9°C) for electric and 62°F (17°C) for gas. “LO” = exhaust too
small or restricted. “HI” = exhaust adequate. (Note: “HOT”
indicates the test was not completed normally. This test must
be initiated when the inside of the dryer is cool). Press Power
Returns to t10
