GA-K8NE-RH Motherboard Layout
ATX
MS/KB
LPT
COMA
IDE2 IDE1
ATX_12V
Socket 754
USB
USB
LAN
SPDIF_O
SPDIF_I
COMB
IT8712
nVIDIA
®
nForce
TM
4(-4X)
PCI1
PCI2
F_USB2
F_USB1
CI
SATAII0
SYS_FAN
F_PANEL
PCI3
CD_IN
PCIE_16
SATAII2
F_USB3
DDR3
DDR2
DDR1
FDD
CODEC
BIOS
GA-K8NE-RH
CPU_FAN
BAT
CLR_CMOS
AUDIO1
F_AUDIO
Marvell phy
AUDIO2
PCIE_1
PCIE_2
PWR_LED
SATAII1
SATAII3
