a
c
‘click’
‘click’
eng
4
frame
When the frame is fastened to the chassis; the chassis is then secured. The bassinet or seat fabric
is fastened to the frame. The frame has 2 frame supports, which ‘click’ onto the 2 frame bearers.
The round side of the frame is always the head end of the bassinet or seat.
step 6 fitting the frame on the chassis
a Squeeze together the squeeze-fastener on the center
shaft. This releases the frame bearers.
b. Place the frame bearers in the upright position.
c Let go of the squeeze-fastener. You will hear a ‘click.’
The frame bearers are now locked.
WARNINGS
• Check that the frame is attached to the chassis. Pick up the frame. If the frame
releases one or both sides of the chassis, press the frame onto the chassis
again until you hear a ‘click’ on both sides.
