Table 10: Device Configuration - Status Definitions
Hardware Revision Hardware version number: Main Board, Interface Board
MAC Address The device ID, in HEXADECIMAL format.
IP Address This field shows IP address of GXP2020
Product Model This field contains the product model information.
Software Version
• Program: This is the main software (firmware) release number, always used to
identify the software (firmware) system of the phone.
• Boot: Booting code version number
System Up Time This field shows system up time since the last reboot.
Registered Indicates whether accounts are registered to the related SIP server(s). GXP2020 can
support four unique SIP profiles.
PPPoE Link Up Inidicates whether the PPPoE connection is enabled (connected to a modem).
Table 11: Device Configuration – Basic Settings Definitions
End User
Password This contains the password to access the Web Configuration Menu. This field is
case sensitive with a maximum length of 25 characters.
IP Address There GXP2020 operates in two modes:
1. DHCP mode: all the field values for the Static IP mode are not used (even
though they are still saved in the Flash memory.) The GXP2020 acquires its
IP address from the first DHCP server it discovers on its LAN. The DHCP
option is reserved for NAT router mode. To use the PPPoE feature, set the
PPPoE account settings. The GXP2020 establishes a PPPoE session if
any of the PPPoE fields are set.
2. Static IP mode: configure all of the following fields: IP address, Subnet
Mask, Default Router IP address, DNS Server 1 (primary), DNS Server 2
(secondary). These fields are set to zero by default.
Multi purpose key 1-7 These options are used to assign a function to the corresponding multi purpose key.
Options available are: “Speed dial”, “Asterisk BLF”, “Presence Watcher” and
“Eventlist BLF”.
Each function is connected to one of the 6 accounts and has a target user ID.
Time Zone This parameter controls the date/time display according to the specified time zone.
Daylight Savings Time This parameter controls time displayed in daylight savings time or not. If set to
“Yes”, then the displayed time will be 1 hour ahead of normal time.
Time Display Format LCD time display in 12 hour or 24 hour format
Date Display Format Choose one of the following formats:
• Year-Month-Day
• Month-Day-Year
• Day-Month-Year
