Using the GXP2020 SIP Enterprise Phone
G ETTING F AMILIAR WITH THE LCD
The GXP2020 has a dynamic and customizable screen. The screen displays differently depending on
whether the phone is idle or in use (active screen). Figure 5 illustrates the IDLE and ACTIVE screens.
Figure 5: LCD in IDLE (on-hook) and ACTIVE (off-hook) mode.
Context Sensitive Soft Buttons
Date and Time
Network Status (Phone IP Address)
SIP phone lines
Customizable logo
6 line selectors
Status Bar
Line Status Indicator and Account Name
.
