Grizzly G9859 - Manual (Page 33)

Ultimate Series Jointers -31-
001 P9859001 BASE
002 P9859002 FENCE SEAT
003 P9859003 TABLE SUPPORT
004 P9859004 TABLE LIFTING ARM
005 P9859005 TABLE SUPPORT
006 P9859006 FRONT HOUSING
007 P9859007 RIGHT REAR HOUSING
008 P9859008 LEFT REAR HOUSING
009 P9859009 TABLE HEIGHT SPINDLE
010 P9859010 TABLE LIFTING ARM
011 P9859011 BASE REAR COVER
012 P9859012 SWITCH BOX
013 P9859013 SWITCH PLATE
014 P9859014 SWITCH (GREEN)
015 P9859015 SWITCH (RED)
016 P9859016 PUSH BUTTON SWITCH (WHITE)
017 PS39M PHLP HD SCR M8-1.25 x 10
018 PK56M KEY 10 x 8 x 260
019 P9859019 SLIDER
020 PW14 FLAT WASHER 5 ⁄
8
"
021 PW08M FLAT WASHER M16
022 PB72M HEX BOLT M16-1.75 x 30
023 PS24M PHLP HD SCR M6-1.0 x 10
024 PW07 FLAT WASHER 5 ⁄
16
"
025 PB07M HEX BOLT M8-1.25 X 25
026 PW01 FLAT WASHER 1 ⁄
2
"
027 PB12M HEX BOLT M12-1.75 X 55
028 PW02 FLAT WASHER 3 ⁄
8
"
029 P9859029 KNOB
030 P9859030 DUST HOOD
031 P9859031 PLATE COVER
032 P9859032 INDEX
033 P9859033 STOP COLLAR
034 PSS20M SET SCREW M8-1.25 X 8
101 P9859101 CUTTERHEAD
102 P9859102 HOUSING HEAD AXLE BOX (R.H.)
103 P9859103 HOUSING
104 P9859104 BEARING 6305-VV
105 P9859105 CIRCULAR NUT
106 P9859106 CUTTERHEAD BELT WHEEL
107 P9859107 CUTTERHEAD STOP PLATE
108 P9859108 CUTTERHEAD COVER (SMALL)
109 P9859109 CUTTERHEAD COVER (SMALL)
110 P9859110 OIL FEEDER 1 ⁄
16
"
111 PLW06M LOCK WASHER M10
112 PB14M HEX BOLT M10-1.5 X 35
113 P9859113 SPECIAL SCREW
114 P9859114 CASE PLATE
115 PW04M FLAT WASHER M10
116 PB65 HEX BOLT 3 ⁄
8
"-16 X 5 ⁄
8
"
117 PSS09M SET SCREW M8-1.25 X 20
118 P9859118 SPECIAL HEX NUT
119 P9859119 CUTTER
120 P985912 0 GIB
121 P985912 1 GIB BOLT
201 P9859201 FENCE SEAT
202 P9859202 ANGLE FENCE SEAT
203 P9859203 ANGLE SEAT FASTEN ROD
204 P9859204 KNOB
205 P9859205 FENCE ROD (LONG)
206 P9859206 FENCE ROD (SHORT)
207 P9859207 ANGLE PLATE
208 P9859208 FENCE
209 P9859209 FENCE ROD
210 P9859210 SPECIAL RETAINER RING
211 PSB13M CAP SCREW M8-1.25 X 30
212 PSB06M CAP SCREW M6-1.0 X 25
213 PSS04M SET SCREW M6-1.0 X 12
214 PSS29M SET SCREW M6-1.0 X 35
215 PN01M HEX NUT M6-1.0
216 PW01 FLAT WASHER 1 ⁄
2
"
217 P9859217 KNOB
218 PW02 FLAT WASHER 3 ⁄
8
"
219 PSB47M CAP SCREW M10-1.5 X 40
220 P9859220 FENCE ADJUSTMENT ROD
221 P9859221 KNOB
301 P9859301 BED
302 P9859302 PLATE
303 PSB26M CAP SCREW M6-1.0 X 12
304 P9859304 NOISE DAMPENER
305 PSB31M CAP SCREW M8-1.25 X 25
306 PSS16M SET SCREW M8-1.25 X 10
307 P9859307 BED PIVOT ROD
308 P9859308 BED PIVOT PIN
309 PSB70M CAP SCREW M12-1.75 X 30
401 P9859401 CUTTERHEAD GUARD
402 PSB06M CAP SCREW M6-1.0 X 25
403 P9859403 SPRING SHAFT HOUSING
404 P9859404 SPRING SHAFT
405 PW06M FLAT WASHER M12
406 PW01M FLAT WASHER 1 ⁄
2
"
407 PSB36M CAP SCREW M12-1.75 X 25
501 P9859501 LIFT ROD COLLAR
502 P9859502 HANDWHEEL
503 P9859503 GEAR
504 P9859504 COLLAR
505 P9859505 LIFT ROD
506 P9859506 GEAR
507 P9859507 LIFT ROD
508 P9859508 SPECIAL RETAINER RING
Ref# Part# Description Ref# Part# Description
