Block diagram – GIGABYTE GA-8I845GE775-G User Manual
Page 7
- 7 -
Block Diagram
LGA775
Processor
Intel 845GE
Intel ICH4
CPUCLK+/- (133MHz)
Host
Interface
266/333MHz
HCLK+/- (100/133MHz)
66 MHz
33 MHz
14.318 MHz
48 MHz
33 MHz
LPC BUS
AGP 4X
AGPCLK
(66MHz)
5 PCI
PCICLK
(33MHz)
6 USB
Ports
ATA33/66/100
IDE Channels
Floppy
LPT Port
PS/2
KB/Mouse
COM
Ports
IT8712F
VGA Port
BIOS
DDR RAM
GMCHCLK(66MHz)
24 MHz
AC97 Link
RTL8110S
AC97
CODEC
MIC
LINE-IN
LINE-OUT
RJ45
