GE Monogram ZDIB50 - Manual (Page 13)

Changing the Lower Access Panel
1. Remove the screw from the top of the lower access
panel and the two screws in the bottom grille area.
Pull forward at the bottom, then down to remove
the panel.
2. Remove the two screws from the top panel trim and
remove the top trim.
3. Carefully slide the panel out.
4. Choose the color you want to show and carefully
slide the panel back into the lower access panel.
NOTE: Be careful not to scratch the panel as it
is inserted.
5. Replace the top trim and screws. Replace the lower
access panel assembly and screws. The top of the
access panel needs to be secured under the two
metal tabs before replacing the screws.
(continued next page)
WARNING: Do not operate the
icemaker with the lower access panel or
control panel removed. Electrical shock
or personal injury could result.
13
Screw
Lower
Access
Panel
Grill
Area
Screws
