General Tire 15-220 User Manual

General Tire Grinding machines

Rotating & oscillating effect ensures
exceptional finishing results.

Precision ground cast iron table.

On-board side mounted spindle storage.

Tilting table for sanding beveled parts.

2” diameter dust outlet with 2” to 4”
adapter fitting included.

5 interchangeable spindle assemblies:
1/4", 1/2", 5/8", 1 1/2", 2" dia.with 100 grit
sand paper.

1 1/2" & 2" spindles come with rubber
drums.

Includes 4 table inserts to accomodate
different spindle sizes.

OSCILLATIONS PER MINUTE
29

LENGTH OF OSCILLATION
15⁄16” (24 mm)

TABLE SIZE
14 1⁄2” x 14 1⁄2” (368 x 368 mm)

TABLE TILT
0° - 45°

TABLE HEIGHT FROM BOTTOM OF BASE
18 5⁄16” (465 mm)

SPINDLE SIZES
1⁄4” TO 2” (6.2 TO 50.8 mm)

DUST CHUTE OUTLET
2” (50.8 mm)

SPINDLE SPEED
1720 RPM

BASE DIMENSIONS (L x W
14 1⁄2” x 14 1⁄2” (368 x 368 mm)

MOTOR
1⁄2 HP, 110 V, 7.5 A

WEIGHT
81 LBS (37 kg)

REVISION 3 FEB 13/07
